Chassis Mount
High Density 500W Medical AC-DC Power Supply
Digital Power’s HDM500 Series are switching power supplies that produce superior output wattages with natural convection. The series include enclosed, open frame and U bracket format with output voltage options of 12V, 15V, 24V and 48V. Featured with compact, low profile footprint, and best-in- class performance, HDM500 Series are optimal for ITE and Medical Applications. Designed with energy saving in mind, Digital Power’s HDM500 Se- ries boasts not only high operating efficiency up to 93%, but also high-power density with full input range of 90- 264VAC. The series is especially suited for medical and healthcare electronics where isolation, leakage current, EMC behavior, and long-term reliability are central design requirements.
| Universal 90-264 VAC input range | |
| Operating altitude up to 5000m | |
| Built-in 12V/0.3A Auxiliary Output, Standby 5V @ 1A with Fan / 0.4A without Fan | |
| High efficiency up to 93%.4000VAC input-to-output isolation | |
| Remote ON/OFF Function | |
| 240 Watt with Free Air Convection | |
| 500 Watt with 30CFM FAN |
| Part Number | HDM500 |
|---|---|
| Input Type | AC-DC Power Supplies |
| AC Input Phase | Single Phase |
| Form Factor | Chassis Mount |
| Function Type | Standard Power Supply |
| Output Voltage | 12V, 15V, 24V, 48V, 3.3V, 5V |
| Output Current | 41.5A, 33.3A, 20.8A, 10.41A, 19.16A, 14A, 9.58A, 4.8A, 20A, 14.66A, 10A, 5A, 15.83A, 11.33A, 7.91A, 3.96A, 16.6A, 12A, 8.33A, 4.17A |
| Output Power | 500W |
| Number of Outputs | 1 |
| Efficiency | 90 - 99% |
| Cooling | Force Air |
| Temperature Range | -30°C to +70°C |
| Compliance | MIL-STD (Defense), IEC 60601 (Medical), CE |
| Safety Certifications | Safety Approval: MIL-STD (Defense), UL/IEC/EN 60601-1, Input-to-Output Isolation: Galvanic, EMC: per IEC 60601-1-2 (Medical), Agency Marks: CE, cURus |
| Electrical Features | PFC, Parallel / Redundancy, Remote Sense / On-Off |
| Market(s) | Military / Defense, Medical & Healthcare, Industrial / AI |
