DPDH240 | Single Phase 240W DIN Rail AC-DC Power Supply

Part Number	DPDH240
Input Type	AC-DC Power Supplies
AC Input Phase	Single Phase
Form Factor	DIN Rail
Function Type	Standard Power Supply
Output Voltage	12V, 24V, 48V
Output Current	16A, 10A, 5A
Output Power	240W
Number of Outputs	1
Efficiency	90 - 99%
Temperature Range	−25°C to +70°C
Compliance	MIL-STD (Defense)
Safety Certifications	UL 61010-1 / UL 61010-2-201 certified for electrical safety., EN / BS EN 61010-1 compliant for measurement and control equipment., High isolation protection up to 3 kVAC withstand voltage., >100MΩ insulation resistance at 500 VDC for reliable operation., EMC compliant with EN55032 and EN61000 industrial standards.
Electrical Features	PFC, Parallel / Redundancy
Market(s)	Military / Defense, Industrial / AI

Model	Description	Power	Output (V)	Select
DPDH120	Single Phase 120W DIN Rail AC-DC Power Supply	120W	12V, 24V, 48V	View Model
DPDH240	Single Phase 240W DIN Rail AC-DC Power Supply	240W	12V, 24V, 48V	View Model
DPDH480	Single Phase 480W DIN Rail AC-DC Power Supply	480W	24V, 48V	View Model
DPDH960	Single Phase 960W DIN Rail AC-DC Power Supply	960W	24V, 48V	View Model
DPDN150	Metal Case 120W DIN Rail AC-DC Power Supply	120W	12V, 24V, 48V	View Model
DPDN240	Metal Case 240W DIN Rail AC-DC Power Supply	240W	24V, 48V	View Model
DPDN480	Metal Case 480W DIN Rail AC-DC Power Supply	480W	24V, 48V	View Model
DPDN75	Metal Case 75.6 W~ 76.8 W DIN Rail AC-DC Power Supply	75.6W, 76.8W	12V, 24V, 48V	View Model
DPSD100S	Step Shape 100W DIN Rail AC-DC Power Supply	100W, 85.2W, 92.2W	Consult factory	View Model
DPSD150S	Step Shape 150W DIN Rail AC-DC Power Supply	150W, 135.6W	Consult factory	View Model
DPSD15S	Step Shape 15W DIN Rail AC-DC Power Supply	15W, 12W	Consult factory	View Model
DPSD30S	Step Shape 30W DIN Rail AC-DC Power Supply	30W, 15W	Consult factory	View Model
DPSD60S	Step Shape 60W DIN Rail AC-DC Power Supply	60W, 22.5W	Consult factory	View Model

Universal 90-264VAC input range
240W continuous output power
High efficiency up to ~93%
Active PFC design
Class I isolation
DC OK relay contact for system monitoring
Compact DIN rail mounting
Wide operating temperature range
